fix(mcp): make every tool's output true for the whole catalogue - #10489
Merged
Conversation
Targeted MCP pass from the 2026-08-19 AI-access audit:
- get_implementation resolves the language from the library's own DB row;
the repository's language_id='python' default made all 1,004 R/Julia/JS
implementations (28% of the catalogue) answer a false 'not found'
- website_url in list_specs / search_specs_by_tags / get_spec_detail
pointed at anyplot.ai/python/{spec}, which 301s into a 404; now the hub
- get_spec_detail attaches per-implementation website_urls AFTER
model_dump - SpecDetailResponse coercion silently dropped them before -
and gains an optional 'libraries' filter so a 15-library spec's ~0.5 MB
response can be trimmed to the libraries actually asked for
- stateless MCP HTTP is now real: passed explicitly to http_app();
the former os.environ.setdefault ran after fastmcp's Settings were
instantiated and never engaged, leaving sessions instance-pinned
Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
The CORS policy applied 2026-08-19 (AI-access audit) is bucket metadata, not code — without this runbook entry a bucket rebuild would silently drop it and cross-origin image embedding would break again. Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
The page whose entire audience is AI agents rendered as title plus a one-line description; it now carries the endpoint URL, a setup snippet, the six tools and fallback pointers (JSON API, llms-full.txt). Includes the changelog entries for the whole MCP pass. Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
Contributor
There was a problem hiding this comment.
Pull request overview
This PR fixes MCP correctness and discoverability across the full anyplot catalogue by (1) resolving non-Python implementations correctly, (2) repairing broken website_url outputs, and (3) making FastMCP stateless HTTP actually take effect for horizontal scaling. It also adds a libraries filter to reduce get_spec_detail payload size, improves the bot-rendered /mcp page content, and documents the anyplot-images bucket CORS policy.
Changes:
- Fix MCP tool outputs: correct language resolution for
get_implementation, correct hubwebsite_urlfor discovery tools, and preserve per-implementation URLs inget_spec_detail. - Enable stateless MCP HTTP mode by explicitly passing
stateless_http=Truetohttp_app(). - Improve agent-facing documentation and safety: add
librariesfiltering, enrich/seo-proxy/mcpbot HTML, and document GCS CORS policy + reapply steps.
Reviewed changes
Copilot reviewed 7 out of 7 changed files in this pull request and generated 2 comments.
Show a summary per file
| File | Description |
|---|---|
api/mcp/server.py |
Fixes MCP tool correctness (language resolution, URLs), adds libraries filter, preserves per-implementation URLs post-Pydantic coercion. |
api/main.py |
Enables stateless MCP HTTP mode via explicit http_app(..., stateless_http=True). |
api/routers/seo.py |
Adds a real bot-visible /mcp body with endpoint, setup snippet, and tool list. |
tests/unit/api/mcp/test_tools.py |
Adds/updates unit coverage for hub URLs, per-implementation URLs, libraries filter, and non-Python language resolution. |
tests/unit/api/test_routers.py |
Adds bot-page test ensuring /seo-proxy/mcp includes connection instructions and tool names. |
agentic/docs/project-guide.md |
Documents the anyplot-images bucket CORS config and re-apply procedure. |
CHANGELOG.md |
Records the MCP correctness fixes, stateless HTTP fix, /mcp bot-page improvements, and CORS documentation under [Unreleased]. |
💡 Add a code-review agent skill or configure MCP servers for context-aware, tailored reviews. Learn more in the docs.
Codecov Report✅ All modified and coverable lines are covered by tests. 📢 Thoughts on this report? Let us know! |
… semantics Copilot review on #10489: the /mcp bot-page test now asserts every documented tool name, and the get_spec_detail docstring states that an empty libraries list means 'all' — agents commonly send [] for 'no filter', and answering it with zero implementations would read as a missing spec. Co-Authored-By: Claude Fable 5 <noreply@anthropic.com>
Contributor
There was a problem hiding this comment.
Pull request overview
Copilot reviewed 7 out of 7 changed files in this pull request and generated no new comments.
Suppressed comments (2)
tests/unit/api/mcp/test_tools.py:283
- The docstring says the response is “multi-megabyte”, but the surrounding code/comments and CHANGELOG describe this payload as ~0.5 MB. Keeping the test description accurate will avoid overstating the size and confusing future readers.
"""The optional libraries filter trims a multi-megabyte response to what's asked for."""
api/routers/seo.py:928
- The
claude mcp addsnippet here uses a different argument order than the human/mcppage (app/src/pages/McpPage.tsx:147). For bots/agents copying this, it’s safer to match the documented CLI form (claude mcp add anyplot --transport http …).
"<pre><code>claude mcp add --transport http anyplot https://api.anyplot.ai/mcp/</code></pre>"
Owner
Author
|
Added one commit from the post-deploy live-verification sweep (49 checks across crawler UAs, machine files, REST, images/CORS, JSON-LD, MCP — zero failures on everything #10487/#10488 deployed): og-card CORS for foreign origins, llms-full.txt lines as |
2 tasks
Owner
Author
|
Correction: the verification-sweep commit mentioned above raced this PR's squash-merge and never landed here — it ships as #10490 (recovered by cherry-picking onto the merged main; the stale recreated branch was deleted). |
MarkusNeusinger
added a commit
that referenced
this pull request
Aug 19, 2026
…10490) ## Summary - og cards now send `Access-Control-Allow-Origin: *` to foreign origins — the global CORSMiddleware answers only the site's own allowlist, so chat UIs fetching a card in-page were blocked (the same in-page-fetch failure class the GCS bucket CORS fix removed). `setdefault` keeps CORSMiddleware's own header for allowlisted origins. - `llms-full.txt` lines list implementations as `{language}/{library}` so the GCS render URL template is instantiable from the file alone; the bare library id forced a second `/specs/{id}` call per image. - Error responses on prerendered pages echo the public path — crawlers hitting a dead spec URL were shown the internal `/seo-proxy/{slug}` routing prefix in the JSON body. - MCP `serverInfo` reports the app version via `FastMCP(version=APP_VERSION)` — it showed fastmcp's package version 3.4.5 while `/health` said 3.1.0. ## Plan Follow-ups found by the post-deploy live-verification sweep (49 checks across crawler UAs, machine files, REST, images/CORS, JSON-LD, MCP; zero failures on everything already deployed). This commit was originally pushed to the #10489 branch but raced its squash-merge — recovered per the repo's merge-race procedure by cherry-picking onto fresh `main`; the recreated stale branch was deleted. ## Test plan - [x] `ruff check` + `ruff format --check` clean; `mypy api core` clean; 1,750 unit + 67 integration tests pass (new tests: og ACAO for a foreign Origin, public path in 404 bodies, llms-full `{language}/{library}` format, MCP version == APP_VERSION) - [ ] After merge + deploy: `curl -sI -H "Origin: https://chat.openai.com" https://api.anyplot.ai/og/home.png | grep -i access-control-allow-origin` → `*`; `curl https://anyplot.ai/llms-full.txt | head` shows `{language}/{library}` entries; MCP `initialize` serverInfo.version == 3.1.0 --------- Co-authored-by: Claude Fable 5 <noreply@anthropic.com>
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Summary
get_implementationfor the non-Python 28% of the catalogue: the repository call carried no language, and itspythondefault made all 1,004 R/Julia/JavaScript implementations answer a false "not found". The language now comes from the library's own DB row (verified live for ggplot2/makie/d3/echarts/chartjs/muix/highcharts in the audit).website_url:list_specs,search_specs_by_tagsandget_spec_detailpointed atanyplot.ai/python/{spec}, which 301s into a 404; all now point at the hub.get_spec_detail's per-implementation URLs — silently discarded bySpecDetailResponsecoercion — are attached aftermodel_dumpand survive.stateless_http=Trueis passed explicitly tohttp_app(). The formeros.environ.setdefault("FASTMCP_STATELESS_HTTP", "true")ran after fastmcp'sSettingswere instantiated and never engaged (reproduced against fastmcp 3.4.5), leaving sessions pinned to one Cloud Run instance with max-instances=3 and no affinity.librariesfilter toget_spec_detail— the full 15-library response carries ~0.5 MB of source, a context-window hazard for the agents the tool serves./mcppage its actual content (endpoint URL,claude mcp addsnippet, the six tools, JSON-API/llms-full.txt fallbacks) — it rendered as title + one line for the exact audience it exists for.anyplot-imagesbucket CORS policy (applied 2026-08-19) in the project guide with the re-apply procedure — bucket metadata does not deploy with the repo, so a rebuild would silently drop it.Plan
The targeted MCP pass from the 2026-08-19 AI-access audit — the final step of the fix order after #10487 (api) and #10488 (app), as agreed. Branch is rebased on the merged main.
Test plan
ruff check+ruff format --checkclean;mypy api corecleanwebsite_urlcorrectness on all three tools, per-implementation URLs surviving the Pydantic roundtrip, thelibrariesfilter, and the/mcpbot-page contentsettings.stateless_httpstaysFalseunder the old env-setdefault route andhttp_appacceptsstateless_httpexplicitlyinitialize+tools/call get_implementation {spec_id: "audiogram-clinical", library: "ggplot2"}returns code (was "not found"); a request withoutmcp-session-idis accepted (stateless);curl -A GPTBot https://anyplot.ai/mcpshows the tool list
